I. Core Performance Parameters (Industry Benchmarking)
| Metric |
Technical Specifications |
Competitive Gap |
| Signal Rate |
224G PAM4 (scalable to 1.6T) |
Supports CPO co-packaged optics integration ⭐ |
| PCB Layers |
16-32 layer AnyLayer HDI |
Trace width/spacing 35μm |
| Insertion Loss |
≤0.5dB/inch @56GHz |
Optimized via Keysight EMPro |
| Thermal Resistance |
0.15℃/W (liquid cooling) |
60% temperature reduction vs. air cooling |
| Power Density |
8W/cm² (@100Gbps port) |
Compliant with ENERGY STAR v8.0 |
Data Insight: IDC 2025 reports the global 10GbE switch market at $18.7B, with liquid cooling penetration rising to 35% and 224G PAM4 demand growing 41% annually.
II. Material & Process Innovations
High-Speed Material Solutions:
- Panasonic MEGTRON 7 (Df=0.0015 @56GHz) – Preferred for 224G backplanes
- Shengyi Synamic 6 (32% cost reduction for domestic alternatives) – Certified by Huawei/Cisco
- Embedded capacitor material (ZBC2000) – 40% power supply noise suppression
Signal Integrity Assurance:
|
|
graph TB |
|
|
A[Differential pair length tolerance ±0.1mm] --> B[Backdrill stub control] |
|
|
C[Hybrid laser drilling accuracy ±15μm] --> D[32-channel TDR testing] |
III. Cost & Delivery Competitiveness
| Service Type |
Technical Specifications |
Price |
Lead Time |
| 16-layer prototype (5 pcs) |
224G PAM4 channels |
$320/board |
48 hours |
| 24-layer mid-volume (1K pcs) |
Liquid cooling + 6 power planes |
$42/unit |
12 days |
| 32-layer + optical engine |
CPO solution (1.6Tbps) |
Custom quote |
30 days |
⚠️ Industry Pain Point: TechInsights 2025 notes signal integrity defects cause 10% of switch returns. This solution reduces risk to 0.3% via DFM automated verification systems.
IV. Reliability Verification System
Environmental Testing:
- 85℃/85%RH aging for 1,000 hours – Insulation resistance maintained >10⁸Ω
- 3,000 thermal cycles (-55℃~125℃) – No microcracks detected
Electromagnetic Compatibility:
- Radiated interference <30dBμV/m @10m (exceeding FCC Class B limits)
- ESD protection ±15kV (IEC 61000-4-2 Level 4)
